M12 L-Type Right Angle Adapter Micro-Change for NMEA2000 CAN Bus DeviceNet

M12 L-Type Right Angle Adapter Micro-Change is designed for NMEA2000, CAN Bus, and DeviceNet. It enables robust and reliable data and power connections in marine, industrial, and automotive settings, featuring an L-shaped design with A-coded pins and a straight angle configuration for optimal performance and versatility. Premier Cable P/N: PCM-0464

Inquiry now
  • Introduction
  • More Products
  • Inquiry

Description

Introduction:

M12 L-Type Right Angle Adapter Micro-Change is designed for NMEA2000, CAN Bus, and DeviceNet. It enables robust and reliable data and power connections in marine, industrial, and automotive settings, featuring an L-shaped design with A-coded pins and a straight angle configuration for optimal performance and versatility. Premier Cable P/N: PCM-0464

Specification:

Type M12 L-Type Connector
Product Name M12 L-Type Right Angle Adapter Micro-Change for NMEA2000 CAN Bus DeviceNet
Premier Cable P/N PCM-0464
Connector A M12 5 Pin, A Code, Male
Connector B M12 5 Pin, A Code, Female
IP Rating IP67
Contact Resistance 3Ω Max.
Insulator Resistance 10 MΩ Min. DC 300V 0.01SEC
Applicable Temperature -25℃ to +80℃
Locking Way Thread

Features:

  1. Splitter Functionality: This M12 A Code L-Type Connector can enable multiple devices to be connected to a single port.
  2. L-Type Configuration: The "L-Type" indicates a right-angle configuration, which can be useful in tight spaces where a straight connector might not fit comfortably.
  3. Connector Gender: The adapter could be designed as a female-to-female, male-to-male, or male-to-female depending on the specific connectivity needs.

Application:

  1. Weather and Environmental Monitoring: Enable connectivity for weather stations, wind sensors, and environmental monitoring devices, supporting navigation.
  2. Thruster and Stabilization Systems: Facilitate communication with thrusters and stabilizer systems, enhancing maneuverability and stability in varying sea conditions.
  3. Autopilot Systems: Provide connections for autopilot control units and heading sensors, allowing for precise vessel steering and coursekeeping.

Drawing:

M12 L-Type Right Angle Adapter Micro-Change for NMEA2000 CAN Bus DeviceNet details
